HH Recirculating Aquaculture System---Waste Heat Energy Recovery System
The Modular Low - Temperature - Difference Waste Heat Recovery System realizes heat transfer by taking advantage of the temperature difference between two media. In the heat transfer process, there is no material migration. High - temperature objects release heat, causing a drop in temperature and a reduction in internal energy, while low - temperature objects absorb heat, leading to a rise in temperature and an increase in internal energy. No extra energy is consumed. This system overcomes technical problems of traditional heat exchange devices, such as easy clogging and scaling, poor corrosion resistance, and high maintenance costs resulting from strict water quality requirements.
Send Inquiry
Description
Products Parameters:
Parameters
SSHRQ - 60/80
SSHRQ - 120
SSHRQ - 160
SSHRQ - 240
SSHRQ - 320
Heat Exchange Process
1*4/15 - stage counter - current heat exchange
2*4 - stage counter - current heat exchange
2*5 - stage counter - current heat exchange
4*4 - stage counter - current heat exchange
4*5 - stage counter - current heat exchange
Primary Side Water Flow
20 - 50m³/h
30 - 70m³/h
40 - 80m³/h
60 - 140m³/h
80 - 160m³/h
Primary Side Water Resistance
72kPa
54kPa
72kPa
54kPa
72kPa
Secondary Side Water Flow
20 - 50m³/h
30 - 70m³/h
40 - 80m³/h
60 - 140m³/h
80 - 160m³/h
Secondary Side Water Resistance
78kPa
58.5kPa
78kPa
58.5kPa
78kPa
Design Pressure
0.5MPa
0.5MPa
0.5MPa
0.5MPa
0.5MPa
Hydrostatic Test Pressure
0.625MPa
0.625MPa
0.625MPa
0.625MPa
0.625MPa
Design Temperature
50°C
50°C
50°C
50°C
50°C
Operating Temperature
≤50°C
≤50°C
≤50°C
≤50°C
≤50°C
Heat Exchange Tube Material
TA1
TA1
TA1
TA1
TA1
Cylinder Material
PP
PP
PP
PP
PP
Unit Dimensions (mm)
29509401269
29509401950
30859402269
295018731950
308518732269
Products advantages:
Modular Design
Adopting a modular design concept, the system can be flexibly installed and used. It can meet the
ultra - wide water heat exchange requirements (ranging from 20 to 480 cubic meters).
Clamp - Type Fastening Connection
The original clamp - type fastening connection method enables quick, stable, and reliable installation.
It also facilitates maintenance, cleaning, combination, and disassembly.
Drawer - Type Heat Exchanger
The original internal drawer - type heat exchanger is anti - scaling, non - clogging, and can be repeatedly
pulled out for cleaning or directly replaced.
Small - Cylinder Heat Exchange Method
By using the small - cylinder heat exchange method, the system has a longer flow path, higher heat exchange
efficiency, and more energy - efficient operation.
Visualization System
With touch control, the system is simple and intelligent. It can automatically control temperature and perform
automatic backwashing, and it can also be interlocked with filter devices.
