Products Parameter
|
Category |
Item | Unit | HH604 |
|---|---|---|---|
|
Model |
Model | / | HH604 |
| Type | / | Four - wheel drive (4×4) | |
| Power | kW | 44.1 | |
|
Dimensions of Tractor |
Dimension (L×W×H) | mm | 3630×1550×2370 |
| Wheel Base | mm | 1860 | |
| Min Ground Clearance | mm | 355 | |
| Minimum Operating Mass | kg | 1780 | |
| Tread | mm | Front tread: 1200(1000 - 1500) adjustable Rear tread: 1200(1000 - 1500) adjustable |
|
|
Matched Power |
Clutch Type | / | Dry - type, single acting (optional double - acting) |
| Engine | / | National III (II 4 cylinder) | |
| Rated Gear Speed | r/min | 2400 | |
|
Working Part |
Gear | / | TEB8 + 2R (optional 8F + 8R) |
| PTO Type | / | 6 spline, Φ35. 1 type | |
| PTO Rated Power | kW | ≥37.5 | |
| PTO Speed | r/min | 540/720 | |
|
Hydraulic System |
Three Point Linkage | / | Rear three - point suspension, CAT1 |
| Hydraulic Output | / | 1 - group valve (optional 2 - group valve) | |
| Hydraulic Adjustment Mode | / | Forced hydraulic system, position control, floating control | |
| Max. Lift Force at Frame Center | kN | ≥10.6 | |
|
Tyre Type |
Standard Tyre Size (Front/Rear) | / | 7.50 - 16/11.2 - 28 |
| Optional Tyre (I) | / | 7.50 - 20/12.4 - 28 | |
| Optional Tyre (II) | / | 6.50 - 16/11.2 - 24 | |
| Other Options | Other Options | / | Cabin, Air brake, ROP, Sunroof (precise selection: cabin, air brake, rollover protection, sunroof) |
Products advantages
Powerful Power, Efficient Operation
Equipped with a 44.1kW China III (II) 4-cylinder engine with a rated speed of 2400 rpm, the machine delivers stable power output. The power take-off (PTO) shaft delivers ≥37.5kW, a dual-speed 540/720 rpm, and is compatible with a 6-spline, Φ35.1-inch transmission. This allows for efficient propulsion under heavy loads, making it easy to plow, harvest, and more.
Four-Wheel Drive, All-Terrain Capability
Adopting four-wheel drive (4×4) mode, the machine boasts an 1860mm wheelbase, a minimum ground clearance of 355mm, and an adjustable front and rear track of 1200mm (1000-1500mm). Whether navigating hilly slopes or muddy fields, the machine offers excellent grip and maneuverability, ensuring uninterrupted operation and minimizing the worry of getting stuck.
Precise Hydraulics, Versatile Adaptability
The hydraulic system supports one valve set (optional two valve sets) with forced hydraulic adjustment and position/float control. The maximum lift force (center of frame) is ≥10.6kN. Combined with the rear three-point hitch (CAT1), it can be attached to implements such as plows and spreaders, providing precise lifting and adjustment to meet diverse agronomic needs.
Flexible Configuration, Practical Adaptability
Standard 7.50-16/11.2-28 tires, with optional 7.50-20/12.4-28 or 6.50 tires available to suit various operating scenarios. Additional features include a cab and air brakes, and 8F-2R (optional 8F-8R) gear ranges for flexible operation, enhancing operational comfort and machine adaptability.
