Product Parameter (Specification)
|
Model |
HH30i, HH35i |
|
Rated weight |
3000kg, 3500kg |
|
The center distance of the load |
500mm |
|
Features and sizes |
|
|
Rising height |
3000mm |
|
Free up height |
145mm |
|
Fork specifications (lxwxt) |
|
|
Hh30i |
1070×122×45mm |
|
Hh35i |
1070×125×50mm |
|
Door frame inclination (front/post) |
6/12 |
|
Length (without fork) |
2750mm |
|
Width |
1265mm |
|
The door frame cannot afford to rise |
2070mm (HH30i), 2180mm (HH35i) |
|
Gate racks rise |
4100mm |
|
Top height |
2150mm |
|
Turning radius |
2515mm |
|
Front suspension |
485mm |
|
Minimum right angle channel width |
2545mm |
|
Wheelbase |
1760mm |
|
Wheel distance |
|
|
Front |
1000mm |
|
After |
970mm |
|
Minimum ground clearance |
|
|
Door frame |
130mm |
|
Frame center |
170mm |
|
Performance |
|
|
Run |
|
|
Full load |
18km/h |
|
Empty load |
18km/h |
|
Rate |
|
|
Full load |
380mm/s |
|
Empty load |
440mm/s |
|
Decrease Speed |
|
|
Full load |
490mm/s |
|
Empty load |
410mm/s |
|
Maximum traction |
|
|
Full load/empty load |
1696/1190kg (HH30i), 1850/1250kg (HH35i) |
|
Maximum climbing |
|
|
Full load/empty load |
15/20% |
|
Weight |
|
|
Self-weight |
4230kg (HH30i), 4560kg (HH35i) |
|
Power and drive |
|
|
Battery |
|
|
Voltage/capacity |
76.8V/200AH |
|
Walking controller |
AC / Megmeet |
|
Pump controller |
AC / Megmeet |
|
Traction motor power (S2-60min) |
16.6Kw |
|
Rating motor power (15min) |
13.5Kw |
|
Work pressure |
17.5Mpa |
|
Tire |
|
|
Front wheel/rear wheel |
28×9-15/6.50-10 |
Product Features & Advantages
1. Eco-Friendly Operation
Powered by an electric motor, producing zero emissions and making it ideal for indoor use and environmentally sensitive areas.
2. Quiet Performance
Operates with low noise levels, ensuring a quieter working environment compared to diesel or gas-powered forklifts.
3. Energy Efficiency
Equipped with advanced battery technology, offering longer operating times and lower energy costs.
4. Compact and Maneuverable
Designed with a compact build, allowing for easy navigation in tight spaces and narrow aisles.
5. Operator Comfort and Safety
Features ergonomic controls, adjustable seating, and enhanced safety systems for a comfortable and secure operating experience.
